Compliance Testing for Shielded Enclosures in Electronics

Compliance testing for shielded enclosures in electronics is a critical process that ensures these devices meet safety and regulatory standards. Shielding is used to prevent electromagnetic interference (EMI) from escaping or entering electronic equipment, which can cause malfunctions, damage, or even fires.

What are Shielded Enclosures?

Shielded enclosures are designed to contain electromagnetic fields within the device itself, preventing EMI from leaking out and affecting other devices nearby. These enclosures use a conductive material such as metal to surround the electronic components, effectively blocking or attenuating electromagnetic radiation. The primary purpose of shielded enclosures is to protect sensitive equipment from unwanted electrical signals that can cause interference.

Shielded enclosures are commonly used in various industries, including:

  • Medical devices: To prevent EMI from affecting life-critical medical equipment

  • Aerospace and defense: To ensure secure communication systems

  • Industrial control systems: To prevent EMI from interfering with process control

  • Telecommunications: To prevent EMI from disrupting phone or internet signals


    • Types of Shielding

    Shielded enclosures use various materials to block electromagnetic radiation. Some common types include:

  • Conductive shielding: Uses a conductive material such as metal to surround the electronic components, effectively blocking electromagnetic radiation.

  • Dielectric shielding: Uses a non-conductive material with high dielectric strength to reduce electromagnetic radiation

  • Hybrid shielding: Combines multiple materials to achieve enhanced EMI attenuation.


    • Shielding effectiveness is measured in decibels (dB), where higher values indicate greater attenuation of electromagnetic radiation. Shielded enclosures can be categorized as:

  • Type 1: Basic shielding with a minimum attenuation level of 50 dB

  • Type 2: Enhanced shielding with a minimum attenuation level of 80 dB

  • Type 3: High-performance shielding with a minimum attenuation level of 100 dB


    • Regulations and Compliance

    Shielded enclosures must comply with various regulations and standards, including:

  • EMC Directive (2014/30/EU): Establishes requirements for electromagnetic compatibility in the European Union

  • FCC Regulations (47 CFR Part 15): Sets standards for radio frequency interference in the United States

  • IEC 61326: Defines safety requirements for electrical equipment


    • Compliance testing involves verifying that shielded enclosures meet these regulations. Testing is typically performed by independent laboratories or third-party certification bodies.

    Compliance Testing Process

    The compliance testing process involves several steps:

    1. Design and planning: Manufacturers must design the shielded enclosure with EMI attenuation in mind, selecting materials and configurations that meet regulatory requirements.
    2. Pre-testing preparation: The manufacturer prepares the device for testing by installing necessary antennas, sensors, and other equipment to measure EMI emissions and susceptibility.
    3. EMC testing: The test laboratory evaluates the devices electromagnetic compatibility using standardized methods such as CISPR 11 (radiated emissions) or IEC 61000-4-6 (immunity tests).
    4. Reporting and certification: Manufacturers receive a test report indicating whether their device meets regulatory requirements, along with any necessary certifications for sale in specific markets.

    Detailed Compliance Testing Steps

    Here are detailed steps for each type of compliance testing:

  • Radiated Emissions (RE):

    • Measure the electromagnetic field strength at various distances from the device using an antenna
    Test the devices ability to suppress unwanted radiation
    Compare results against regulatory limits
  • Conducted Emissions (CE):

    • Measure the electromagnetic current flowing through cables and connectors
    Verify that devices meet regulatory requirements for conducted emissions
    Use specialized equipment such as a LISN (Line Impedance Stabilization Network)
  • Immunity Tests:

    • Evaluate the devices susceptibility to various types of EMI, including power frequency magnetic fields
    Test the devices ability to withstand exposure to different types of electromagnetic radiation
    Compare results against regulatory limits

    Compliance Testing Equipment

    Some common equipment used in compliance testing includes:

  • Spectrum analyzers: Measure the electromagnetic field strength across various frequencies

  • Power sensors: Measure the power level of electromagnetic radiation

  • Antennas and probes: Used to measure radiated emissions at different distances from the device

  • LISN and injection impedance: Measure conducted emissions through cables and connectors


    • QA

    Here are some additional details on compliance testing for shielded enclosures in electronics:

    Q: What is the main purpose of shielded enclosures?
    A: The primary purpose of shielded enclosures is to prevent electromagnetic interference (EMI) from escaping or entering electronic equipment.

    Q: What types of materials can be used for shielding?
    A: Conductive materials such as metal, dielectric materials with high dielectric strength, and hybrid combinations of multiple materials can be used for shielding.

    Q: How is shielding effectiveness measured?
    A: Shielding effectiveness is typically measured in decibels (dB), where higher values indicate greater attenuation of electromagnetic radiation.

    Q: What are the main regulations governing shielded enclosures?
    A: The EMC Directive (2014/30/EU) and FCC Regulations (47 CFR Part 15) set standards for electromagnetic compatibility, while IEC 61326 defines safety requirements for electrical equipment.

    Q: What is the typical testing process for shielded enclosures?
    A: Compliance testing involves design and planning, pre-testing preparation, EMC testing using standardized methods, reporting, and certification.

    Q: Are there any specific types of compliance testing?
    A: Yes, including radiated emissions (RE), conducted emissions (CE), and immunity tests.

    Q: What equipment is used in compliance testing?
    A: Spectrum analyzers, power sensors, antennas and probes, LISN and injection impedance are commonly used for various aspects of compliance testing.

    Q: Are there any standards or regulations specific to industries using shielded enclosures?
    A: Yes, such as the IEC 61326 standard for medical devices and military specifications for aerospace applications.
